Commercial Elevators
Commercial Elevators
₹5,50,000
Starting Price
- 6-26 Passengers
- 0.5–2.5 m/s Speed
- MR & MRL Options
- IS 17900 Compliant
- Commercial Elevator Specifications
- Capacity ------ 6 – 26 passengers (408 kg – 1768 kg)
- Speed ------ 0.5 m/s – 2.5 m/s
- Door Width ------ 800mm – 1100mm
- Pit Depth------ 1200mm – 1500mm (varies by speed/capacity)
Elevate Your Home. Literally.
Vyonn commercial elevators are engineered for high-traffic environments. Available in Machine Room (MR) geared traction and Machine Room-Less (MRL) gearless configurations, with capacities from 6 to 26 passengers and speeds up to 2.5 m/s. Every elevator uses open-architecture controllers (Sharp), Montanari traction machines, and Fermator door systems – so you get global-quality components without MNC pricing or lock-in.
By default, all commercial elevators require a pit (as per building code). We provide complete civil work guidance – shaft dimensions, pit depth, machine room specifications, and structural load calculations – so your civil contractor gets it right the first time.
Features That Make a Difference
Choose Your Drive Technology
MRL GEARLESS TRACTION (Recommended for Most Projects)
- No machine room needed. PMSM motor sits inside the shaft. Ideal for G+4 to G+15. Most energy-efficient option. Lower long-term operating costs.
MR GEARED TRACTION (Heavy Duty / High Rise)
- Dedicated machine room on terrace. Best for G+6 to G+20+ and high-capacity requirements. Proven technology with easy maintenance access. Slightly higher energy consumption but handles heavier loads.
Who Is a Commercial Elevator For?
- Office buildings and corporate towers
- Shopping malls and retail complexes
- Hotels, resorts, and hospitality venues
- Residential group housing societies and high-rise apartments
- Hospitals and institutional buildings (general passenger use)
- Mixed-use commercial-residential developments
Why Commercial Owners Across Delhi-NCR Choose Vyonn
Global Components, Local Service
Montanari machines, Fermator doors, Sharp controllers – same components used by MNC elevator brands, at 30-40% lower cost with local service and support.
Open Architecture = No Lock-In
Your building will never be held hostage by proprietary AMC contracts. Any qualified technician can maintain a Vyonn elevator.
Builder-Friendly Process
We provide complete civil drawings, shaft specifications, and load calculations before you pour concrete. Coordinate with your structural engineer from day one.
Multi-Lift Project Expertise
Banks of 2, 4, or 6 elevators? We design group control systems with coordinated dispatching for optimal wait times.
- Commercial Elevator Specifications
- Capacity ------ 6 – 26 passengers (408 kg – 1768 kg)
- Speed ------ 0.5 m/s – 2.5 m/s
- Door Type ------ Fermator centre-opening or telescopic side-opening
- Drive Options ------ MRL Gearless (PMSM) | MR Geared Traction
- Traction Machine ------ Montanari (Italy)
- Controller ------ Microprocessor, Sharp (open architecture)
- Door Width ------ 800mm – 1100mm
- Pit Depth------ 1200mm – 1500mm (varies by speed/capacity)
- Headroom ------ 4200mm – 4800mm
- Power Supply ------ 415V, 3-phase, 50Hz
- Safety ------ Full IS 17900 compliance: overspeed governor, safety gear, light curtain, ARD, intercom, fire-service mode
Get Quote
Ready to Install? Contact Us Today!
- Phone: +91 83778 48110
- sales.vyonnlifts@gmail.com
- Address: B-381, Sector C-8, Trans Delhi Signature City, Ghaziabad 201103
MRL Commercial Elevator (8 passengers, G+5): Starting from ₹5,50,000
Free site survey. Transparent quotation within 48 hours. No obligation. MR Commercial Elevator (13 passengers, G+8): Starting from ₹7,50,000
Free site survey. Transparent quotation within 48 hours. No obligation. High-Capacity (20+ passengers): Custom quotation based on specs
Free site survey. Transparent quotation within 48 hours. No obligation.Frequently Asked Questions
MR (Machine Room) elevators have a dedicated room on the terrace for the motor and controller. MRL (Machine Room Less) eliminates this room – machinery sits inside the shaft. MRL saves space and energy but MR handles heavier loads and higher speeds. We recommend the right type based on your building height, traffic, and budget.
A typical 8-passenger elevator needs approximately 1600mm x 1700mm shaft space. We provide exact shaft dimensions during the free site survey, customized to your building’s layout.
Absolutely. We recommend engaging with us during the design phase so we can provide shaft dimensions and structural specifications before construction begins. This avoids costly modifications later.
30 days from order confirmation for standard configurations. Multi-lift bank projects may take 45-60 days depending on the number of units.
Yes. For buildings with 2 or more elevators, we provide coordinated group control systems that optimize wait times and distribute traffic evenly.
